MIC5 Series Ignition Controller

Based on the new MOTORTECH ignition controller platform the MIC5 with 500 mJ primary energy is designed for gas engines with up to 20 cylinders.

High ignition energy, accurate spark timing and diversified online diagnostics help to improve engine efficiency, spark plug life and availability of the equipment under the strictest emission regulations. The controller is fully customer configurable via Laptop.

  • Adjustable spark duration and intensity
  • Constant spark intensity via adjusted duration
  • 500 mJ primary energy (700 mJ boost)
  • Ignition diagnostics (primary and secondary)
  • Fault memory with trend data
  • Integrated CANopen and Modbus RTU interface
  • Easy access per USB port
  • 18 to 32 VDC supply voltage
  • 20 ignition outputs
  • 250 VDC primary voltage
  • 500 mJ primary energy (700 mJ boost)
  • 0.1° crankshaft accuracy
  • Triggered by 1, 2 or 3 pickups (magnetic, hall effect or inductive / configurable)
  • Multiple timing control via
    – Potentiometer
    – Speed curve
    – 0-20 mA analog input
    – 0-10 V analog input
  • Multiple energy control via MOST (MOTORTECH Output Stage Technology)
  • Programmable firing order
  • 1 multipurpose output (GPO)
  • 1 Auxiliary Synchronization Output (ASO) which can support a detonation control system (e.g. DetCon) or fuel injection pump controllers
  • Ignition release input
  • Go/NoGo output
  • Overspeed shutdown function
  • Access controlled
